1 Intro 1.1 Reasons for this Book 1.2 Scope of this Book 1.3 Some Rules for a Better Understanding 2 Basics of OPA Noise and Gain 2.1 Noise Sources of an OPA 2.2 General Aspects of OPA Gains 2.3 Test of "Test-OPA-M" with the Adapted Fig. 1.
7 Test Arrangement 2.3.1 Spice parameters for the Test-OPA-M and test arrangement 2.3.2 Noise voltage 2.3.3 Noise Current 2.3.
4 Slopes 2.4 Résumé 3 Mathcad Worksheets for Chapter 2 3.1 MCD-WS: Test-OPA-M Open Loop Gain 3.2 MCD-WS: Test-OPA-M Noise Production 4 Non-Inverting OPA Gain Stages 4.1 The Noise Production of the Non-Inverting (Series Configured) OPA Gain Stage 4.2 Output Related 4.3 Input Related 4.4 Résumé 5 Mathcad Worksheet for Chapter 4 5.
1 MCD-WS: Non-Inverting Gain Stage 6 Inverting OPA Gain Stages 6.1 The Noise Production of the Inverting (Shunt Configured) OPA Gain Stage 6.2 Output Related 6.3 Input Related 6.4 Résumé 6.5 Important Note Concerning an Additional Load Zx(f) at the (+) Input of the OPA in Fig. 6.2 7 Mathcad Worksheets for Chapter 6 7.
1 MCD-WS: Inverting Gain Stage 7.2 MCD-WS: Proof 8 Phono-Amp with OPAs 8.1 The Noise Production of the Phono-Amp 8.2 Main Equations to Calculate the Output Voltage noise and SNs of the Fig. 8.1 RIAA Phono-Amp - Correlated and Un-Correlated 8.2.1 Main equations for Fig.
8.9 (à la MCD-WS 9.3): 8.2.2 Main equations for Fig. 8.11 (à la MCD-WS 9.3): 8.
2.3 Main equations for Fig. 8.1 incl input load (à la MCD-WS 9.3): 8.3 Résumé 9 Mathcad Worksheets for Chapter 8 9.1 MCD-WS: Phono-Amp + 0.0 Ohm with Test-OPA-M 9.
2 MCD-WS: Phono-Amp + 1.0 k Ohm with Test-OPA-M 9.3 MCD-WS: Phono-Amp + StaCar with Test-OPA-M Part II Solutions Other Than Slopes of 0.0 dB/dec or -10.0 dB/dec 10 The Correlation Matter 10.1 OPA with all its Independent Equivalent Input Noise Sources 10.2 The Voltage Noise Question 10.2.
1 The 100% un-correlated state 10.2.2 The 100% correlated state 10.2.3 The general state 10.3 The Current Noise Question 10.3.1 The 100% un-correlated state 10.
3.2 The 100% correlated state 10.3.3 The general state 10.4 Real OPAs 10.4.1 Model vs. Data Sheet - Results 10.
4.2 Recommended approach to find the correlation state of OPAs, demonstrated by application of the example OPA AD797 10.5 Résumé 11 Mathcad Worksheets for Chapter 10 11.1 MCD-WS: Test-OPA-01 Correlation Basics 11.2 MCD-WS: AD797 Correlation Basics 11.3 MCD-WS: LT1128 Correlation Basics 12 OPA Noise Modelling 12.1 Intro 12.2 Noise Traces of OPAs 12.
3 Goals 12.4 The Voltage Noise Solution 12.5 The Current Noise Solution I - Non-inverted and Non-Correlated Version 12.6 The Current Noise Solution II - Inverted and Correlated Version 12.7 The Final Replacement OPA with Independent and Adjustable Noise Sources 12.7.1 OPA without any correlation of the noise sources 12.7.
2 OPA including inverted and 100% correlated current noise sources 12.7.3 Other correlation arrangements 12.8 Comparison Results 13 Mathcad Worksheets for Chapter 12 13.1 MCD-WS: Traces 13.2 MCD-WS: Phono-Amp + StaCar with Test-OPA-N 13.3 MCD-WS: Phono-Amp + 1.0 k Ohm with Test-OPA-N 13.
4 MCD-WS: Phono-Amp + 0.0 Ohm with Test-OPA-N Part III Solutions for a Selection of Real Op-Amps 14 Noise Traces for the Simulation Model of OPAs - Created with the Example OPA NE5534A 14.1 Intro 14.2 The Simulation Model''s Traces Presented by the Manufacturer 14.3 Data Collection 14.4 Decision about the "right" Traces 14.4.1 Voltage Noise 14.
4.2 Current Noise 14.5 Further Material of Noise Trace 14.6 The Final NE5534AN Simulation Model for the New NE5534AN 14.7 What About the Correlation of the Current Noise Sources of the Original Model? 14.8 What about the OPA''s Input Resistance Rn 14.9&.
