About the Authors xv Preface xvii Acknowledgments xix Acronyms xxi 1 Introduction 1 1.1 Overview 1 1.2 Microgrid Concept and Capabilities 2 1.3 Microgrid Structure 2 1.4 Microgrids in the Future Smart Grids 5 1.5 Microgrids-Integrated Power Grids 7 1.6 Current Trends and Future Directions 8 1.6.
1 Dynamic Behavior of MGs and Their Impacts on Power Grids 9 1.6.2 Microgrid-Based Ancillary Services 10 1.6.3 Dynamic Modeling and Control 10 1.7 The Book Content and Organization 10 References 12 Part I Individual Microgrids 15 2 Microgrid Dynamic Modeling: Concepts and Fundamentals 17 2.1 Introduction 17 2.2 Dynamics and Modeling 19 2.
3 Fundamental Analysis Tools and Requirements 20 2.3.1 State-Space (Small-Signal) Modeling 21 2.3.1.1 Finding Differential Equations 21 2.3.1.
2 Park and Clark Transformations 22 2.3.1.3 Linearization 23 2.3.1.4 State-Space Representation 24 2.3.
1.5 Interconnecting Modules 25 2.3.2 Detailed Modeling 28 2.3.3 Simplification Methods 28 2.3.3.
1 Truncation (Regular Perturbation) 29 2.3.3.2 Residualization (Singular Perturbation) 30 2.3.3.3 Aggregation 30 2.3.
3.4 Sensitivity Analysis 32 2.3.4 Prony Analysis 33 2.3.5 Large-Signal Modeling 35 2.4 Small-Signal Modeling of Microgrid Components 35 2.4.
1 DC-AC Converter (Inverter) 36 2.4.2 AC-DC Converter (Rectifier) 36 2.4.3 DC-DC Converter (Chopper) 37 2.4.4 LC Filter 39 2.4.
5 Power Network 39 2.4.5.1 Virtual Resistor Calculation 40 2.4.6 Loads 41 2.4.6.
1 Constant RL Impedance Load 42 2.4.6.2 Constant Power Load (CPL) 43 2.4.6.3 Motor Load 44 2.4.
6.4 Active Load 44 2.4.7 Energy Resources and Storages 46 2.4.7.1 Wind Generation Unit 46 2.4.
7.2 Photovoltaic Generation Unit 50 2.4.7.3 Battery 52 2.4.7.4 Super-Capacitor 55 2.
5 Small-Signal Modeling of Microgrid Controllers 58 2.5.1 Primary Control Strategies 58 2.5.1.1 Grid-Forming Strategy 59 2.5.1.
2 Grid-Following Strategy 65 2.5.2 Secondary Control 68 2.5.3 Higher Control Levels 70 2.6 Large-Signal Modeling: An Example 70 2.6.1 Governing Equations on Synchronverter 70 2.
6.2 Nonlinear State-Space Representation 72 2.7 Summary 72 References 73 3 Microgrid Dynamic Modeling: Overall Modeling and Case Studies 79 3.1 Introduction 79 3.2 Overall Microgrid Dynamic Modeling 80 3.2.1 Common Reference Frame 80 3.2.
2 Microgrid General State-Space Model 81 3.2.3 Grid Model 81 3.3 Small-Signal Modeling of DC and AC Microgrids 82 3.3.1 A Grid-Connected PV 82 3.3.2 Grid-Connected AC Microgrids 84 3.
3.3 Islanded AC Microgrids: The Detailed Model 85 3.3.4 Islanded AC Microgrids: A Sensitivity Analysis-Based Simplified Model 86 3.3.4.1 Removing/Reconfiguration Process of Modules 86 3.3.
4.2 DLFMs Comparison of the Detailed and Simplified Models 88 3.3.4.3 The Oscillatory DLFM Comparison 89 3.3.5 Islanded AC Microgrids: Aggregated Single-Order Model 90 3.3.
5.1 General Steps of Modeling 90 3.3.5.2 Virtual Swing Equation-Based Single-Order Model 91 3.3.6 Islanded DC Microgrid 93 3.4 Large-Signal Modeling of Microgrids 96 3.
4.1 Model Validation 96 3.4.2 Time-Domain Simulations 98 3.5 Summary 99 References 100 4 Microgrids Stability 103 4.1 Introduction 103 4.2 Stability Definition and Classification 104 4.3 Basic Requirements 106 4.
3.1 Eigenvalue Analysis 106 4.3.2 Participation Matrix 107 4.3.3 Sensitivity Analysis 108 4.4 Small-Signal Stability Analysis 109 4.4.
1 Grid-Connected PV 109 4.4.1.1 Sensitivity Analysis: LC Filter Parameters 111 4.4.1.2 Sensitivity Analysis: Coupling/Grid Line Length 111 4.4.
1.3 Sensitivity Analysis: PLL Gains 112 4.4.1.4 Sensitivity Analysis: Current Control Gains 113 4.4.1.5 Sensitivity Analysis: DC Voltage Control gains 113 4.
4.2 Grid-Connected AC Microgrids 114 4.4.2.1 Sensitivity Analysis: Grid Strength Study 115 4.4.2.2 Sensitivity Analysis: Interaction of GFL DERs 116 4.
4.3 Islanded AC Microgrids 117 4.4.3.1 Sensitivity Analysis of Droop Gains 117 4.4.3.2 Sensitivity Analysis of Virtual Impedance 118 4.
4.3.3 Stability Analysis of Secondary Control 120 4.4.3.4 Sensitivity Analysis of GFL DER Parameters 122 4.4.3.
5 Weakness of AC Microgrids 123 4.4.3.6 Relative Stability Improvement Using Grid-Supporting Control Strategy 125 4.4.4 Islanded DC Microgrids 129 4.5 Transient Stability 131 4.5.
1 Power Sharing Stability in AC Microgrids 131 4.5.2 Synchronverter Stabilization 134 4.5.2.1 Adaptive Backstepping Stabilizing Method 134 4.5.2.
2 Simulation Results 136 4.6 Summary 137 References 139 5 Microgrid Control: Concepts and Fundamentals 143 5.1 Introduction 143 5.2 Fundamentals and Requirements 143 5.2.1 Introduction to Control Systems 143 5.2.2 Control Objectives and Challenges 144 5.
2.3 Control Architectures 146 5.3 Control Strategies for Power Converters 149 5.3.1 Introduction 149 5.3.2 Grid-Following Power Converters 150 5.3.
2.1 Current Control 151 5.3.2.2 Synchronization Algorithm 153 5.3.3 Grid-Forming Power Converters 153 5.4 Hierarchical Control 155 5.
4.1 The Control Hierarchy 155 5.4.2 Control Layers 156 5.5 Primary Control 157 5.5.1 Droop Control 160 5.5.
1.1 Droop Control for Inductive Grids 162 5.5.1.2 Droop Control for Resistive Grids 163 5.5.1.3 Droop Control for Resistive-Inductive Grids 163 5.
5.1.4 Discussion on the Conventional Droop Control 164 5.5.1.5 Droop Control for DC Grids 167 5.5.2 Virtual Impedance 168 5.
5.3 A Simulation Study for Primary Control of AC Microgrids 169 5.5.3.1 Case Study 169 5.5.3.2 Simulation Results 169 5.
6 Secondary Control 173 5.6.1 Secondary Control Functions and Strategies 173 5.6.1.1 Secondary Control Functions 173 5.6.1.
2 Secondary Control Strategies 175 5.6.2 Centralized Secondary Control 175 5.6.3 Distributed Secondary Control 176 5.6.3.1 Communication Network as a Graph 176 5.
6.3.2 Average-Based DISC 177 5.6.3.3 Consensus-Based DISC 177 5.6.3.
4 Event-Triggered DISC 178 5.6.4 Decentralized Secondary Control 179 5.6.4.1 Washout Filter-Based DESC 180 5.6.4.
2 Local Variable-Based DESC 180 5.6.4.3 Estimation-Based DESC 180 5.6.5 A Simulation Study for Secondary Control of AC Microgrids 182 5.6.5.
1 Case Study and Controller Implementation 182 5.6.5.2 Simulation Results 182 5.7 Central Control 185 5.8 Global Control 186 5.9 Summary 186 References 187 6 Advances in Microgrid Control 197 6.1 Introduction 197 6.
2 Advanced Control Synthesis 198 6.2.1 Advanced Control Techniques 198 6.2.1.1 Optimal Control 199 6.2.1.
2 Robust Control 200 6.2.1.3 Nonlinear Control 200 6.2.1.4 Intelligent Control 200 6.2.
2 Model Predictive Control 201 6.2.2.1 MPC for Microgrids 202 6.2.2.2 Finite Control Set Model Predictive Control 203 6.2.
3 Model Predictive Control of DC Microgrids with Constant Power Loads 204 6.2.3.1 Case Study and Dynamic Modeling 205 6.2.3.2 Design Methodology 208 6.2.
3.3 Real-Time Hardware in the Loop Results 210 6.2.4 Hybrid Fuzzy Predictive Control for Smooth Transition of AC Microgrids 210 6.2.4.1 Case Study and Dynamic Modeling 213 6.2.
4.2 Control System Design 216 6.2.4.3 Simulation Results 218 6.3 Virtual Dynamic Control 221 6.3.1 Concept and Structure 221 6.
3.2 Virtual Synchronous Generator (VSG) 223 6.3.2.1 VSG Applications 225 6.3.3 Virtual Dynamic Control of DC Microgrids 226 6.3.
3.1 Dynamic Improvement of DC Microgrids Using Virtual Inertia Concept 226 6.3.3.2 Case Study and Simulation Results 228 6.4 Resilient and Cybersecure Control 230 6.4.1 Microgrid as a Cyber-Physical System 230 6.
4.2 Communication Requirements 232 6.4.3 Cybersecurity 233 6.4.3.1 Network/Data Cyber Threats on Microgrids 234 6.4.
3.2 Distributed Secondary Control Under Network Cyber Attacks 235 6.4.3.3 Cyberattack Detection 236 6.4.3.4 Cyberattack Mitigation 240 6.
4.4 Event-Triggered Control 240 6.4.4.1 Event-Triggered Secondary Control of AC Microgrids 242 6.4.4.2 Physical and Control Layers 242 6.
4.4.3 Secondary Control Design 243 6.4.4.4 Case Study and Simulation Results 245 6.5 Summary 250 References 250 Part II Interconnected Microgrids 263 7 Interconnected Microgrids: Opportunities and Challenges 265 7.1 Introduction 265 7.
2 An Overview 267 7.3 Architectures of Interconnected Microgrids 269 7.4 Benefits, Challenges, and Research Fields 271 7.5 Operation of Interconnected Microgrids 272 7.6 Vacancies for Future Research 273 7.6.1 IMG Dynamic Modeling 273 7.6.
2 IMG Stability Analysis 273 7.6.3 IMG Control 274 7.7 Summary 274 References 275 8 Modeling of Interconnected Microgrids 285 8.1 Introduction 285 8.2 Interconnection Method 286 8.3 Module Modeling 287 8.3.
